Product Description
| Sensing & Power Input | 190-240 Vac . |
| Burden | 500 VA |
| Output Power- Continuous | 73 Vde at 3.5 Ade (255w) |
| Output Power - Forcing(240 Vac Input Power) | 105 Vdc at5 Adc (525w) |
| Regulation | I .0% |
| Remote Voltage Adjustment Range | 土10% with 2000 ohm rheostat |
| 土5% with 1000 ohm rheostat | |
| Frequency Compensation | Adjustable |
| Roll off frequency | 54-61 Hz for 60 Hz |
| 45-51 Hz for 50 Hz . | |
| Operation | Weight 6.5 oz. |
| Operating Temperature | -40°C to+60°C |
| Storage Temperature | -65°C to+ 85°C |
| Power Dissipation | 8 w atts maximum . |
| Size | 3.94"LX 2.66WX 2.20: H |
| Voltage Buildup | Internal provisions for automatic voltage build up from generator residual voltage as low as 10 Vac. |
| EMI Suppression | Internal Electromagnetic Interference |
| Filter (EMI Filter ) |
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
