Product Description
| Voltage | 190-240VAC | ||||
| Frequency | 50/60Hz,Jumper selectable | ||||
| Voltage | Max 73VDC@220VAC input | ||||
| Current | Continuous 3.5A , intermittent 7A for 10 secs(52/105VDC) | ||||
| Resistance | Min.15 ohm , Max 100ohm | ||||
| Voltage Build-up | residual voltage at avr terminal >5VAC | ||||
| Voltage Regulation | <±1% WITH 4% engine governing | ||||
| Operating Temperature | (-40°C to +60°C | ||||
| Storage Temperatue | (-65°C to +85°C | ||||
| External Volts Adjutment | ±10% with 2k ohm 1 watt trimmer | ||||
| EMI Suppression | Internal electromagnetic interference filtering | ||||
| Unit Power Dissipation | Max.8 watt | ||||
| Power | 50Hz system presets knee point at 45-51Hz | ||||
| Dimensions | 10x6.7x4.8cm | ||||
| Weight | 0.25kg | ||||
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
