Product Description
| Options | Parameters |
| Working voltage | DC8V----36V Continuous |
| Power consumption | Standby：24V：MAX 1W |
| Working：24V：MAX 5W | |
| AC Voltage Input | 1P2W 30VAC-276VAC(ph-N) |
| 2P3W 30VAC-276VAC(ph-N) | |
| 3P4W 30VAC-276VAC(ph-N) | |
| Rotate speed sensor Frequency | 200-10000Hz |
| MAX Accumulating Time | 99999.9Hours（Min Store time:6min） |
| Fuel Relay Output | 16Amp DC+VE Supply voltage |
| Start Relay Output | 16Amp DC+VE Supply voltage |
| Programmable Relay output 1 | 5Amp DC+VE Supply voltage |
| Programmable Relay output 2 | 5AMP Non-contact-Normal open--Normal close output |
| Programmable Relay output 3 | 5AMP Non-contact Normal Open output |
| Programmable Relay output 4 | 5AMP Non-contact normal open output |
| Programmable Relay output 5 | 5AMP Non-contact-Normal open--Normal close output |
| Excitation output | Max 1AMP DC+VE supply voltage |
| Switch value input | Available if connecting with Battery - |
| Working condition | -20-65℃ |
| Storage condition | -40-85℃ |
| Protection Level | IP54：when waterproof rubber gasket is added between controller and its panel |
| Overall dimension | 210mm*160mm*50mm |
| Panel cutout | 186mm*142mm |
| Weight | 0.9Kg |
