Product Description
| Sensing Input | Terminal 0-110V = 90~150V Terminal 0-220V = 175~260V Terminal 0-380V = 350~520V |
| Power Input | Voltage 100~264 VAC, Single Phase |
| Output | Voltage Max. 90 VDC at 207 VAC Current Continuous 4 ADC, Intermittent 10A for 10 sec. |
| Thermal Drift | 0.05% per °C change in AVR ambient |
| DROOP Input | Max. input 0.33A Burden 10 ? 0.07A for 5% droop (PF=0) |
| Under Frequency Protection | U/F Potentiometer 45~60 Hz |
| Voltage Regulation | < ± 1% (with 4% engine governing) |
| External Volts Adjustment | ±8% @ 1 K? |
| Voltage Build-up | Residual volts at AVR terminal > 5 VAC |
| EMI Suppression | Internal Electromagnetic Interference Filtering |
| Exciter Resistor | DC Resistance 20~100 ? |
| Analogue Input | Max. Input ±5 VDC Input Resistance 1 K? 1V for 5% generator volts |
| Unit Power Dissipation | Max. 12 Watt |
| Environment | Vibration : 1.5 G @ 5~30 Hz , 5.0 G @ 30~500 Hz Relative Humidity : < 95% Operating Temperature : -40~60 °C Storage Temperature : -40~85 °C |
| AVR Controls Functions | VOLT : Voltage Adjustment STAB : Stability Adjustment U/F : UFRO Knee Point Set (U/F: Under Frequency Protection) DROOP : Droop Adjustment TRIM : Analogue Input Adjustment DIP : U/V Rate Set |
