Product Description
Vltage Regulation < ±1%
Soft Start Voltage Ramping
Sensing Voltage Loss Protection
120 or 240 VAC Sensing, Jumper Selectable
Under Frequency Roll Off Protection
With Under Frequency LED Indicator
Sensing Input:
Voltage:220/380/440VAC , 1 phase 2 wire
Frequency:50-60Hz nominal
Voltage input:100-300VAC
Field output:
Voltage:max90VDC at 240VAC input
Current:continuous 5A,intermittent 20A for 10 se
Resistance:15 ? minimum
Regulation:+/-0.5% RMS with 4% engine governing
Voltage build up: residual voltage at avr terminal >5VAC
External Voltage Adustament:+/15% with 5k ohm 1 watt trimmer
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
