Product Description
| Brushless AVR | EA05A |
| Sensing Input Voltage | 220/380/440VAC , 1 phase 2 wire |
| Frequency | 50-60Hz nominal |
| Voltage input | 100-300VAC , 1 phase 2 wire |
| output Voltage | max90VDC at 240VAC input |
| Current | continuous 5A,intermittent 7A for 10 secs |
| Resistance | 12 Ω minimum , max 100Ω |
| Regulation | +/-0.5% RMS with 4% engine governing |
| Voltage build-up | residual voltage at avr terminal >5VAC |
| External Voltage Adjustment | +/-7% with 1k ohm 1 watt trimmer |
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
