Features
<±5% Regulation
220/400 VAC Programmable Input
Rugged Compact Design
With Under Frequency Protection
Soft Start Voltage Raping
EMI Suppression
Built-in high Capacity 15Amp Fuse
Specification
Sensing Input Voltage: 220/400 VAC,1 phase 2wire
Power Input Voltage: 180~260VAC 1phase 2 wire
Output Voltage: Max.90VDC @ 240VACCinput
Current: Continuous 6A
Intermittent 12A for 10SEE
Resistance: Min.10Ω Max.100Ω
Volts Regulation: <±1%(with 4% engine governing)
Voltage Build-up: Residual volt at AVR terminal >5VAC
External Volts Adjustment: ±7% with 1KΩ 1watt trimmer
Soft Start Ramp Time: 3 sec.
Unit Power Dispensation: Max.8 Watt
EMI Suppression: Internal Electromagnetic Interference Filtering
Thermal Drift: 0.05% per Celsius change in AVR ambient
Under Frequency protection: 60HZ system presets knee point at 57HZ (Factory settings
50HZ system presets knee point at 47HZ
Environment
Vibration 3G@100~2K HZ
Operating Temperature -40~65Celsius
Relative Humidity<95%
Storage Temperature -40~85Celsius
