Product Description
| REGUL ATION ACCURACY | +/- 0.5% rated steady state conditions |
| VOLTAGE DRIFT | voltage change, for 50C T amb change |
| RESPONSE TIME | 1 cycle |
| OPERATING TEMPERATURE | -30C:+70C |
| EXCITER FIELD RESISTANCE | 8 Q2 (min) : 20 Q2(max) |
| INPUT/OUTPUT DATA | |
| SUPPLY VOLTAGE | 170 -270 V |
| POWER SUPPLY | 350 VA (max) |
| POWER DISSIPATED | 15 W (max) |
| VOLTAGE SENSING | 170- 270 V |
| OUTPUT VOLTAGE (DC) | 30 V |
| OUTPUT CURRENT (DC) | 5 A (max, servizio continuo)(max, continuos) |
| OUtPUT CURRENT (DC) | 8 A (max, in forzamento 1 minuto)(max forcing one minute) |
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
