Product Description
| SPECIFICATION | SE350 REGULATOR |
| Sensing:& Power Input | 190-240Vac |
| Burden | 500VA |
| Output Power-Continuous | 73 V dc at 3.5 A dc (255w) |
| Output Power - Forcing(240 Vac Input Power) | 105 V dc at 5 A dc (525w) |
| Regulation | 1.00% |
| Remote Voltage Adjustment Range | ± 10% with 2000 ohm rheostat ± 5% with 1000 ohm rheostat |
| Frequency Compensation | Adjustable |
| Roll off frequency | 54-61 Hz for 60 Hz |
| 45-51 Hz for 50 Hz | |
| Operation | Weight 6.5oz |
| Operating Temperature | - 40°C to + 60° C |
| Storage Temperature | -65°C to + 85° C |
| Power Dissipation | 8 watts maximum |
| Size | 3.94" LX2.66"WX2.20: H |
| Voltage Buildop | Internal provisions forautomatic voltage build up from generator residual voltage as low as 10 Vac. |
| BMI Suppression | Internal Electromagnetic Interference Filter (EMI Filter) |
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
