Product Description
| Features | jumper selectable 120(95-132)VAC,240(190-264)VAC, single phase 2wire | |
| Sensing Input Voltage | 220/400VAC, 1 phase 2wire | |
| Frenquency | 50-60Hz nominal | |
| Voltage Input | Max 90VDC at 207VAC input | |
| Resistance | 15Ω minimum | |
| Regulation | <± 1% RMS with 4% engine governing | |
| Voltage Build-up | residual voltage at avr terminal >5VAC | |
| External Voltage Ajustment | :+/-7% with 1k ohm 1 watt trimmer | |
| * Voltage regulation less than +/-1% | ||
| * Drive infrared LED to control excitation | ||
| * 50/60 Hz optional | ||
| * Under frequency protection | ||
| * Adjustable stability | ||
| * External voltage trimmer applicable | ||
Fu'an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
Factory inspection
The professional person responsible for the quality of supervision and control in the entire process.
Element testing
In order to get the superior quality we only use selected good element
Assembles products
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
