PERFORMANCE

Working pressure :12VDC/24VDC

Working angle:28 degree.

Working Current:Less than 4A

DC resistance:4.5OM

the maximum torque:4Nm

Hit:20G

Vibration:Less than 500Hz.

PERFORMANCE

Force:

6.2 lb. (27.5N)

Operating Stroke:

0.80 in. (21 mm)

Response Time (10-90%, 2-19 mm):

35 msec.

ELECTRICAL POWER INPUT

Operating Voltage:

12 or 24V DC

Nominal Operating Current:

12V DC version:

4.0A

24V DC version:

2.0A

Maximum Current:

12V DC version:

5.8A

24V DC version:

3.1A

ENVIRONMENTAL

Operating Temperature:

-40 to +95 °C (-40 to +200 °F)

Relative Humidity:

up to 100%

Vibration:

20g, 20-500 Hz

Shock:

20g @ 11 msec.

PHYSICAL

Weight:

4.75 lb. (2.2kg.)

Mounting:

Requires camshaft bearing retainer kit

P3000pump

KT275

P7000 pump

KT276

Mating Connector:

EC1300

Mating Cable Harness:

CH1215
