Product Description
| GAVR-15B | ||
| Sensing Input Voltage | 220/400VAC,1phase2wire | |
| Power Input Voltage | 180~240VAC,1phase2wire | |
| Out put Voltage | Max.90VDC@240VACinput | |
| Current | Continuous 6A | |
| Intermittent | 12Afor10SEE | |
| Resistance | Min.10ΩMax100Ω | |
| VoltageBuild-up | >5VAC | |
| External Volts Adjustment | +/-7% with 1KΩ1watt trimmer | |
| Unit Power Dissipation | Max.8Watt | |
| Under Frequency | Protection60Hzsystempresetskneepointat57Hz | |
| FactorySettings | 50Hzsystempresetskneepointat47Hz | |
Fu’an Shaluo Electronics co.Ltd is a manufacturer of generator accessories, Our company has established a long term and stable business relationship with a number of domestic agents and retailers.
The professional person responsible for the quality of supervision and control in the entire process.
In order to get the superior quality we only use selected good element.
Aimed at enabling the production department to manufacture and assemble the product as efficiently as possible.
