Replace DSE3110 Generator Auto Start Controller Panel Compatible Original Deep Sea DSE 3110 MPU Control Module

The manual forms part of the product and should be kept for the entire life of the product. If the product is passed or supplied
to another party, ensure that this document is passed to them for reference purposes.
This is not a controlled document. You will not be automatically informed of updates.
The DSE 3000 series module has been designed to allow the operator to start and stop the engine/generator, and
if required, transfer the load.
The user also has the facility to view the system operating parameters via the LCD display.
The DSE 3000 module monitors the engine, indicating the operational status and fault conditions, automatically
shutting down the engine and giving a true first up fault condition of an engine failure. The LCD display indicates the
fault.
The powerful microprocessor contained within the module allows for incorporation of a range of enhanced features:
• Text based LCD display
• True RMS Voltage monitoring.
• Engine parameter monitoring.
• Fully configurable inputs for use as alarms or a range of different functions.
• Engine ECU interface to electronic engines (specify on ordering)
• Magnetic pickup interface for engine only applications (specify on ordering)
Using a PC and the 3000 series configuration software allows alteration of selected operational sequences, timers
and alarm trips.
Additionally, the module’s integral fascia configuration editor allows adjustment of this information.
A robust plastic case designed for front panel mounting houses the module. Connections are via locking plug and
sockets.
Feature ​：
• Back-lit icon LCD display
• Front panel editing
• LED and LCD alarm indication
• Power Save mode
• CAN and Magnetic Pick-up/Alt. versions available (specify on ordering)
• PC configurable
• 6 Digital inputs
• 4 Outputs (2 configurable on Magnetic Pick up/Alt., 4 configurable on CAN version) ​ Alternative configuration
• Configurable timers and alarms
• Remote Start input
• Generator voltage display
• Generator frequency display
• Battery voltage display
• Engine speed display
• Hours counter
• Engine pre-heat
• Comprehensive shutdown or warning on fault condition ​ BENEFITS
• Tamper-proof hours counter provides accurate information for monitoring and maintenance periods
• Multiple engine parameters are monitored simultaneously
• Module can be configured to suit individual applications
• Suitable for engine only applications
• Compatible with a wide range of CAN engines
• Uses Configuration Suite PC software for simplified configuration
• IP65 rating (with optional gasket) offers increased resistance to water ingress
• Licence-free PC software

• Back-lit icon LCD display
• Front panel editing
• LED and LCD alarm indication
• Power Save mode
• CAN and Magnetic Pick-up/Alt. versions available (specify on ordering)
• PC configurable
• 6 Digital inputs
• 4 Outputs (2 configurable on Magnetic Pick up/Alt., 4 configurable on CAN version)

Alternative configuration
• Configurable timers and alarms
• Remote Start input
• Generator voltage display
• Generator frequency display
• Battery voltage display
• Engine speed display
• Hours counter
• Engine pre-heat
• Comprehensive shutdown or warning on fault condition

BENEFITS
• Tamper-proof hours counter provides accurate information for monitoring and maintenance periods
• Multiple engine parameters are monitored simultaneously
• Module can be configured to suit individual applications
• Suitable for engine only applications
• Compatible with a wide range of CAN engines
• Uses DSE Configuration Suite PC software for simplified configuration
• IP65 rating (with optional gasket) offers increased resistance to water ingress
• Licence-free PC software
